HIGHLIGHTS:

  • Teck completes 21-hole Phase 2 diamond drilling campaign for 10,540.4m

  • Confirmation of porphyry copper mineralization at Cerro Alacrán with broad zones of visible chalcopyrite intersected

Azure Minerals Limited (ASX: AZS) (“Azure” or “the Company”) is pleased to provide an update on results from its 100%-owned Alacrán project (“Alacrán” or the “project”) located in Sonora, Mexico.

Project operator Minera Teck S.A. de C.V. (“Teck”), a 100%-owned subsidiary of Canada’s largest diversified resource company, Teck Resources Limited, is currently earning back into the project. Work conducted during 2018 represents the second year of activity in a total four-year program which entitles Teck to earn back a 51% share of the project by sole-funding US$10 million of exploration expenditures and making cash payments to Azure totaling US$500,000. Upon reaching an initial 51% interest in the project, Teck may further increase its interest to 65% by sole funding an additional US$5 million in expenditures over a further two years and making cash payments to Azure totaling an additional US$1.5 million.

Teck’s Year 2 work program comprised geological, geochemical and geophysical surveys, followed by the Phase 2 diamond drilling campaign. The major focus of the drilling was testing the porphyry copper potential at Cerro Alacrán with other targets including epithermal precious metals targets at Cerro San Simon and Cerro Colorado.

At Cerro Alacrán, several drill holes intersected broad zones (greater than 100m drill width) of porphyry-style copper mineralization containing low to moderate copper grades. Better drill intercepts include:

  • ALA-18-001 118.0m @ 0.17% Cu from 164.5m

  • ALA-18-003 131.7m @ 0.25% Cu from 42.3m

  • ALA-18-011 137.0m @ 0.19% Cu from 418.9m

  • ALA-18-014 177.3m @ 0.21% Cu from 587.2m

The Phase 2 drilling program comprised 21 holes for 10,540.4m and the two programs completed in 2017 and 2018 total 35 holes for 15,455.1m. Full and complete assays from the Phase 2 program have been received and mineralized drill intersections are detailed in Tables 2 & 3.

Sixteen of Teck’s holes targeted the Cerro Alacrán prospect where porphyry-style copper mineralization lies beneath a blanket of copper oxides and chalcocite (an acid-soluble copper sulphide mineral) which was previously drilled by the Mexican Geological Survey in the 1970s and by Grupo Mexico in the 1990s. The remaining five holes targeted epithermal-style precious metals mineralization at Cerro San Simon and Cerro Colorado.

2018 Drill Program

The 2018 drilling program was designed to test the overall mineral potential in the property, focusing in three areas, Cerro Alacrán, Cerro San Simon and Cerro Colorado (see Figure 1).

Figure 1: Areas targeted in Teck’s 2018 work program and other prospects

Twenty-one diamond drill holes were completed, totaling 10,540.4m, distributed as follow:

  1. 16 holes for 9,147.5m in Cerro Alacrán;

  2. 4 holes for 988.4m in San Simon; and

  3. 1 hole for 404.5m in Cerro Colorado.

Collar location data for the 2018 drill holes is provided in Table 1.

Assay results for the 2018 drill program have been received and mineralized intersections are listed in Tables 2 & 3. Intersections were calculated using lower grade cut-offs of 0.1g/t for gold and 0.1% for copper respectively. All mineralized intersections quoted have a minimum thickness of ten meters and include a maximum of three meters of internal dilution.

Cerro Alacrán:

The primary focus of the 2018 drill program was to test the potential of Cerro Alacrán to host a large porphyry copper±molybdenum±gold deposit. This program was the first modern drilling since historical drilling undertaken in the 1970s and 1990s intersected wide zones of low-grade copper oxides and chalcocite mineralization in the supergene zone.

Drilling has confirmed that copper mineralization is contained within an area covering at least 2km x 1.5km (see Figure 2), with room for expansion.

Copper mineralization within the oxide zone (turquoise) and sulphide transition zone (chalcocite) was intersected in many drill holes, returning broad intercepts of low-grade copper and gold (for example: 131.7m @ 0.25% Cu & 0.11ppm Au from 42.3m in ALA-18-003). Mineralization is hosted in strongly altered breccias extending from surface to depths of around 200m.

Deeper drilling within the sulphide zone extended the previously known extents of strongly altered porphyry intrusions. Broad intercepts of disseminated chalcopyrite and porphyry-style veins containing chalcopyrite and molybdenite mineralization. As with the overlying oxide and transition zones, drilling within the primary sulphide zone intersected wide zones of low to moderate-grade copper mineralization, including: 137.0m @ 0.19% Cu from 418.9m in ALA-18-011 and 177.3m @ 0.21% Cu from 587.2m in ALA-18-014.

Figure 2: Drill holes at the Cerro Alacrán porphyry copper target



Cerro San Simon:

San Simon is a high-sulfidation epithermal gold-silver target associated with a stratigraphic horizon of vuggy silica. this was previously drill tested by Teck in 2017 and Azure in 2016, and gold and silver intersections included:

  • MDPD-025: 31.5m @ 0.54ppm Au (ASX: 25 August 2016)

  • MDPD-035: 17.0m @ 0.32 ppm Au (ASX: 15 November 2016)

  • ALA-17-004: 63.0m @ 0.47 ppm Au (ASX: 10 May 2018)).

The objective of the 2018 San Simon drill campaign was to test the continuity of the gold and silver bearing horizon that extends from the San Simon hill north towards the Loma Bonita gold-silver deposit. A total of 988.4m of drilling was completed in four drill holes. The holes drilled through the target horizon however no significant gold or silver mineralization was intersected.

Cerro Colorado:

Cerro Colorado is a high-sulfidation epithermal gold-silver target with potential for underlying porphyry-style copper-molybdenum-gold mineralization at depth.

The only hole drilled at Cerro Colorado in the 2018 campaign (ALA-18-020) intersected a porphyry for most of the drill hole with alteration and a finely disseminated pyrite-silica hydrothermal brecciation from 120m to 300m (6% average pyrite content over this interval). The hole ended at 404.5m with no significant precious or base metal mineralization intersected.

Summary

Results from the 2018 exploration and drill program confirm the prospectivity of the Alacrán property to host porphyry-associated copper-molybdenum-gold mineralization, specifically at Cerro Alacrán.

The overall copper grades contained within the broad intersections are of low to moderate grade, in the range of 0.15% to 0.30% Cu, however, the presence of extensive mineralization over several square kilometers and the broad intercepts of disseminated chalcopyrite and porphyry-style veining supports the concept of a large mineralized system.

Drilling has not closed off the mineralized body at Cerro Alacrán either laterally or at depth. Further drilling will be required to define both the overall size of the body and to test for higher grade zones.

Background to Alacrán Project

Azure earned 100% ownership of the Alacrán project from Teck in October 2016. In December 2016, Teck elected to exercise its right to earn back an ownership interest in the Alacrán project.

Work conducted during 2018 represents the second year of activity in a maximum four-year period for Teck to earn back a 51% share in the project.

Under the back-in agreement, Teck has an option to sole-fund US$10 million of exploration expenditure in accordance with the following schedule, and make cash payments to Azure totaling US$500,000:

On or Before:Cumulative Aggregate Work Expenditures (US$)Interest Earned
First anniversary$2,000,000 (Expenditure met)0%
Second anniversary$4,000,000 (Expenditure met)0%
Fourth anniversary$10,000,000 51%

Upon reaching an initial 51% interest in the project, Teck may further increase its interest to 65% by sole funding an additional US$5 million in expenditures over a further two years and making cash payments to Azure totaling an additional US$1.5 million. In this case, Azure will retain a contributing 35% interest in the Alacrán project. Grupo Mexico retains a 2% NSR royalty.

-ENDS-

For inquiries, please contact:

Tony Rovira
Managing Director
Azure Minerals Limited
Ph: +61 8 9481 2555

Media & Investor Relations
Michael Weir / Cameron Gilenko
Citadel-MAGNUS
Ph: +61 8 6160 4903



Competent Person Statements:

Information in this report that relates to Exploration Results for the Oposura Project is based on information compiled by Mr Tony Rovira, who is a Member of The Australasian Institute of Mining and Metallurgy and fairly represents this information. Mr Rovira has sufficient experience relevant to the style of mineralisation and type of deposit under consideration, and to the activities undertaken, to qualify as a Competent Person as defined in the 2012 Edition of the Joint Ore Reserves Committee (JORC) Australasian Code for Reporting of Exploration Results, Mineral Resources and Ore Reserves. Mr Rovira is a full-time employee and Managing Director of Azure Minerals Limited and consents to the inclusion in the report of the matters based on his information in the form and context in which it appears.

Information in this report that relates to previously reported Exploration Results has been crossed-referenced in this report to the date that it was reported to ASX. Azure Minerals Limited confirms that it is not aware of any new information or data that materially affects information included in the relevant market announcements.



Table 1: Drill hole information


TABLE 2: Gold mineralised drill intercepts of >10.0m @ >0.1g/t Au


TABLE 3: Significant copper mineralised drill intercepts of >10.0m @ > 0.1% Cu
