Vancouver, British Columbia – Fabled Silver Gold Corp. (“Fabled” or the “Company”) (TSXV: FCO; OTCQB: FBSGF, and FSE: 7NQ) reports that it has completed the planning for a Phase 2 exploration diamond drill program on the Santa Maria Property in Parral, Mexico.

Peter Hawley, President, CEO reports; “As mentioned before, the past year of exploration diamond drilling, underground diamond drilling, definition diamond drilling, and finally surface mapping and sampling,  has been not only aggressive, but has resulted in over 6,900 samples collected and analyzed. This massive input of data has led our stream lined analytical team to new important understandings of the structural and mineralization controls on the western sector of the property where approximately 80% of our efforts over the past year were focused.

Before we report our new findings, I would like to extend our thanks to our Project Manager Joaquin Rodriguez and senior geologist Edgar Rojas for their contribution to these important steps forward.”

When the Company embarked on this project, we were of the opinion this was a low sulfidation epithermal system deposit and contained two veins of interest. The Santa Maria and Santa Maria Dos veins.

Following the completion of the Phase 1 drilling we have now had time to “stop chasing the bit” and have compiled the total data collected. Through analysis of the data generated many things have become clear.

The veins thought to be the Santa Maria veins are in fact mineralized breccias at the contacts or within diorite dikes. Furthermore, there are different generations of structural / mineralization controls and some of the 2021 exploration drilling intercepted one of the secondary mineralized dike structures which is the Santa Maria off-set to the northeast which remains open in all directions, such as the last hole drilled on the Santa Maria deposit on the western sector of the property, where we intercepted 21.90 meters grading 5.29 g./t Au in 349.21 g/t Ag Eq with an astonishing 4,821.98 g/t Ag eq with 86.10 g/t Au.

Using the valuable 2021 drilling information, we will apply the new structural interpretation and the Santa Maria signature and controls to the rest of the property, paying particular attention to the mineralized structures / breccias.  Due to the association with the diorite dikes the present focus of sampling is the dikes, the mineralization found within or with a relationship to them.

Detailed field mapping and structural analyses led by our senior team including our Project Manager has resulted in the below, property wide interpretation  in preparation for Phase 2 exploration drill targets.

As previously reported past surface sampling of the “Northeast Structure” has reported surface sampling of 1.25 meters of 72.12 g/t Ag Eq and 2.20 meters grading 116.20 g/t Ag Eq including 206.80 g/t Ag Eq over 0.80 meters. In addition, it is now realized that drill hole SM20-11 intercepted the Northeast secondary mineralized structure and reported 3 separate mineralized zones; Zone 1 from 62.80 – 95.59 meters grading 31.72 g/t Ag Eq over the 26.90 meters including 1.20 meters grading 110.11 g/t Ag Eq; Zone 2 from 101 – 103.20 reporting 118.57 g/t Ag Eq over the 2.20 meters and the third Zone which returned 3.50 meters grading 40.80 g/t Ag Eq.

The 2022 field work and observations for the final planning of the Phase 2 Exploration Diamond Drill Program. To support the drill hole targeting the following has been completed.

  • 258 new surface samples taken to date
  • 11,388 square meters of detailed geological mapping
  • 237 structural stations for detailed structural interpretations

The 56 sample results listed below are partial surface sampling results from the field evaluations using a 30 g/t silver cut-off, as there are too numerous results to report. See Table 1 below;

Table 1 – Santa Maria Property Field Samples, 30 g/t Ag cut-off

Sample No.Width(meters)Gold(g/t)Silver(g/t)Silver Eq. *(g/t)Rock Unit
9551862.160.0263.0064.03Quartz Vein
9551900.690.2030.7040.99Stockwork
9551910.500.0259.1060.13Quartz Vein
9551990.600.0499.00101.06Stockwork
9552010.600.0392.2093.74Stockwork
9552190.400.27131.00144.89Hydrothermal Breccia
9552200.820.1532.1039.82Hydrothermal Breccia
9552240.900.0862.7066.82Hydrothermal Breccia
9552270.400.3342.2059.18Hydrothermal Breccia
9552300.500.0152.9053.41Hydrothermal Breccia
9552320.800.0136.4036.91Hydrothermal Breccia
9552340.700.1187.9093.56Hydrothermal Breccia
9552351.000.0662.0065.09Hydrothermal Breccia
9552370.900.05106.00108.57Hydrothermal Breccia
9552381.000.2284.1095.42Undifferentiated Breccia
9552391.200.0534.7037.27Tectonic Breccia
9552401.000.0643.4046.49Undifferentiated Breccia
9552420.800.0390.0091.54Undifferentiated Breccia
9552441.100.0149.2049.71Undifferentiated Breccia
9552461.000.0750.8054.40Undifferentiated Breccia
9552471.000.0548.1050.67Undifferentiated Breccia
9552481.000.06132.00135.09Undifferentiated Breccia
9552490.800.5285.70112.45Undifferentiated Breccia
Sample No.Width(meters)Gold(g/t)Silver(g/t)Silver Eq. *(g/t)Rock Unit
9552501.000.2092.20102.49Undifferentiated Breccia
9552511.001.81273.00366.10Undifferentiated Breccia
9552560.800.2230.9042.12Hydrothermal Breccia
9552571.000.5866.2096.04Hydrothermal Breccia
9552591.100.0990.9095.53Undifferentiated Breccia
9552600.600.61182.00213.38Undifferentiated Breccia
9552610.800.0643.3046.39Undifferentiated Breccia
9552620.800.23241.00252.83Undifferentiated Breccia
9552630.700.84332.00375.21Undifferentiated Breccia
9552670.701.4728.80104.42Undifferentiated Breccia
9552700.800.0475.0077.06Undifferentiated Breccia
9552710.700.0199.70100.21Undifferentiated Breccia
9552741.100.0533.3035.87Undifferentiated Breccia
9552820.200.1460.2067.40Hydrothermal Breccia
9552830.500.02227.00228.30Hydrothermal Breccia
9552901.280.0833.4037.52Limestone
9553040.210.1833.2042.46Breccia
9553050.700.3891.80111.35Quartz Vein
9553060.380.0981.2085.83Quartz Vein
9553070.250.37111.00130.03Quartz Vein
9553081.000.8873.90119.17Quartz Vein
9553130.400.519.0035.23Quartz Vein
9553161.000.2451.9064.25Quartz Vein
9553210.200.0538.2040.77Quartz Vein
9553220.200.0637.0040.09Quartz Vein
9553350.400.0647.1050.19Hydrothermal Breccia
9553360.220.0364.6066.14Hydrothermal Breccia
9553370.450.0769.7073.30Hydrothermal Breccia
9553390.300.0344.7046.24Intrusive
9553410.220.0636.0039.09Hydrothermal Breccia
9553431.531.1759.60119.78Intrusive
9553470.310.96248.00297.38Quartz Vein
9553480.273.04266.00422.38Quartz Vein

** Ag Equivalent (“Ag Eq”) grade is calculated using $20 per ounce Ag and $1,600 Au.

As a result of work to date, 6 mineral / structural trends or potential dilation zones have been observed and are potential targets. These are as follows;

  1. Stockwork North – East mineralized breccia system, successfully intercepted in drill hole SM20-11,
  2. North mineralized oxidized breccia system,
  3. North 2 Dike System and mineralized breccias
  4. North East breccia system
  5. Middle Santa Maria Deposit trend
  6. East Santa Maria Deposit trend

See Figure 1 below.

Figure 1 – Santa Maria Property Exploration Mineralized System Targets

The designed exploration diamond drill program is in two phases, of which, the second phase is result driven based on first phase results.

Exploration Drill Target #1 is a  stockwork quartz veining North – East mineralized breccia system, which was successfully intercepted in drill hole SM20-11, as discussed above. A total of 4 first priority holes for a total of 800 meters have been planned along with 300 meters in 1 hole as second priority. The results of the first 4 holes will determine if this area is followed up. See Figure 2 below.

Figure 2 – Drill Target #1 Longitudinal and Cross Section

Exploration Drill Target #2 is the north trending mineralized oxidized breccia system and the intersection of the north east breccia system which may create a dilation zone. Four first priority drill holes have been planned for a total of 1,220 meters and if successful an additional 1,100 meters of second priority drill holes have also been planned. See Figure 3 below.

Figure 3- Drill Target #2 Longitudinal and Cross Section

Exploration Drill Target #3 is the north 2 trending dike system and related mineralized breccias where 3 first priority holes totaling 650 meters have been planned and if successful an additional 550 meters in 2 holes planned. See Figure 4 below.

Figure 4- Drill Target #3 longitudinal and Cross Section

Exploration Drill Target #4 is the north east trending mineralized breccia system and the interception of the north east breccia zone which may create a dilation zone. Two first priority drill hole totaling 570 meters have been planned plus if successful and additional 4 secondary holes totaling 1,220 meters have been outlined. See Figure 5 below.

Figure 5- Drill Target #4 longitudinal and Cross Section

Exploration Drill Target #5 is the middle Santa Maria Deposit trend extension and the intersection of the north east breccia system targeting a potential dilation zone. One first priority drill hole has been planned totaling 250 meters with a results driven second priority hole of 320 meters planed for follow up if warranted

Figure 6- Drill Target #5 Longitudinal and Cross Section

Finally, exploration Drill Target #6 is the Santa Maria Deposit trend east extension where various mineralized dikes have been found on surface. One first priority drill hole has been planned totaling120 meters with a results driven second priority hole of 200 meters planed for follow up if warranted.

Figure 7- Drill Target #6 Longitudinal and Cross Section

Exploration Drill Pad Location Update

The exploration drilling pads / sites are presently being prepared in advance with ample water for surface drilling. The drill stations with the lowest environmental impact have been determined and any exploration drill stations outside the currently permitted area have been incorporated in to an amendment to our current drill permit and presently being with SEMARAT. While this process is on-going exploration drilling of the permitted sites is scheduled to begin mid June 2022.

QA QC Procedure

Analytical results of sampling reported by Fabled Silver Gold represent core samples that have been sawn in half with half of the core sampled and submitted by Fabled Silver Gold staff directly to ALS Chemex, Chihuahua, Chihuahua, Mexico. Samples were crushed, split, and pulverized as per ALS Chemex method PREP-31, then analyzed for ME-ICP61 33 element package by four acid digestion with ICP-AES Finish. ME-GRA21 method for Au and Ag by fire assay and gravimetric finish, 30g nominal sample weight.

Over Limit Methods

For samples triggering precious metal over-limit thresholds of 10 g/t Au or 100 g/t Ag, the following is being used:

Au-GRA21 Au by fire assay and gravimetric finish with 30 g sample. Ag-GRA21 Ag by fire assay and gravimetric finish.

Fabled Silver Gold monitors QA/QC using commercially sourced standards and locally sourced blank materials inserted within the sample sequence at regular intervals.

About Fabled Silver Gold Corp.

Fabled is focused on acquiring, exploring and operating properties that yield near-term metal production. The Company has an experienced management team with multiple years of involvement in mining and exploration in Mexico. The Company’s mandate is to focus on acquiring precious metal properties in Mexico with blue-sky exploration potential.

The Company has entered into an agreement with Golden Minerals Company (NYSE American and TSX: AUMN) to acquire the Santa Maria Property, a high-grade silver-gold property situated in the center of the Mexican epithermal silver-gold belt. The belt has been recognized as a significant metallogenic province, which has reportedly produced more silver than any other equivalent area in the world.

Mr. Peter J. Hawley, President and C.E.O.
Fabled Silver Gold Corp.
Phone: (819) 316-0919
[email protected]

For further information please contact: [email protected]

The technical information contained in this news release has been approved by Peter J. Hawley, P.Geo. President and C.E.O. of Fabled, who is a Qualified Person as defined in National Instrument 43-101 – Standards of Disclosure for Mineral Projects.

Neither the TSX Venture Exchange nor its Regulations Service Provider (as that term is defined in the policies of the TSX Venture Exchange) does accept responsibility for the adequacy or accuracy of this news release.

Certain statements contained in this news release constitute “forward-looking information” as such term is used in applicable Canadian securities laws. Forward-looking information is based on plans, expectations and estimates of management at the date the information is provided and is subject to certain factors and assumptions, including, that the Company’s financial condition and development plans do not change as a result of unforeseen events and that the Company obtains any required regulatory approvals.

Forward-looking information is subject to a variety of risks and uncertainties and other factors that could cause plans, estimates and actual results to vary materially from those projected in such forward-looking information. Some of the risks and other factors that could cause results to differ materially from those expressed in the forward-looking statements include, but are not limited to: impacts from the coronavirus or other epidemics, general economic conditions in Canada, the United States and globally; industry conditions, including fluctuations in commodity prices; governmental regulation of the mining industry, including environmental regulation; geological, technical and drilling problems; unanticipated operating events; competition for and/or inability to retain drilling rigs and other services; the availability of capital on acceptable terms; the need to obtain required approvals from regulatory authorities; stock market volatility; volatility in market prices for commodities; liabilities inherent in mining operations; changes in tax laws and incentive programs relating to the mining industry; as well as the other risks and uncertainties applicable to the Company as set forth in the Company’s continuous disclosure filings filed under the Company’s profile at www.sedar.com. The Company undertakes no obligation to update these forward- looking statements, other than as required by applicable law.
